Brand

Hikvision

Product Type

Turret Camera

Product Code

DS-2CD1347G0-L

General

Linkage Method

Upload to FTP/NAS, notify surveillance center, send email, trigger recording, trigger capture

Software Reset

Reset via web browser and client software

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Startup And Operating
Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

Web Client Language

English and Ukraine

General Function

Anti- flicker, heartbeat, mirror, privacy masks, password reset via e-mail

Power Consumption And Current

12 VDC, 0.37 A, maximum. 4.5 W
PoE (802.3af, 36 V to 57 V), 0.13 A to 0.08 A, maximum. 4.5 W

Power Supply

12 VDC ± 25%, PoE: 802.3af, Type 1 Class 3, reverse polarity protection

Power Interface

Ø 5.5 mm coaxial power plug

Camera

Image Sensor

1/2.7" Progressive Scan CMOS

Minimum Illumination

Color: 0.001 Lux (F1.0, AGC ON)

Shutter Speed

1/3 s to 1/100, 000 s

Slow Shutter

Yes

Wide Dynamic Range

120 dB

P/N

P/N

Angle Adjustment

Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

Lens

Lens Type & FOV

2.8 mm, horizontal FOV 102°, vertical FOV 54°, diagonal FOV 121°
4 mm, horizontal FOV 80°, vertical FOV 43°, diagonal FOV 95°

Lens Mount

M12

Aperture Type

Fixed

Aperture

F1.0

Depth Of Focus

2.8 mm: 3.1 m to ∞
4 mm: 3.6 m to ∞

Illuminator

Smart Supplement Light

Yes

Supplement Light

White

White Light Range

Up to 30m

Video

Main Stream

50Hz: 20 fps (2560 × 1440) 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (2560 × 1440) 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)

Sub Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Video Compression

Main Stream: H.265 /H.265/H.264 /H.264
Sub-Stream: H.265/H.264/MJPEG

Video Bit Rate

32 Kbps to 8 Mbps

H.264 Type

Baseline Profile/Main Profile/High Profile

H.265 Type

Main Profile

Region Of Interest (ROI)
